Open Access

Revision of the spider genera Ariston O. P.-Cambridge, 1896 and Siratoba Opell, 1979 (Arachnida: Araneae: Uloboridae) with description of two new species

  • Lidianne Salvatierra1, 2Email author,
  • Ana Lúcia Tourinho1, 3 and
  • Antonio D Brescovit4
Zoological Studies201453:28

DOI: 10.1186/s40555-014-0028-0

Received: 16 February 2014

Accepted: 19 May 2014

Published: 28 June 2014

Abstract

Background

Ariston O. P.-Cambridge, 1896 and Siratoba Opell, 1979 are two poorly known genera of the spider family Uloboridae, which together comprise six nominal species previously described. This study provides an update of the taxonomic status for both genera and the description of two new species for Ariston.

Results

The male of Ariston albicans O. P.-Cambridge, 1896 is described and illustrated for the first time, based on specimens from Chiapas, Mexico; Ariston reticens Gertsch & Davis, 1942 is transferred to Siratoba, and Siratoba sira Opell, 1979 is considered its junior synonym; Ariston spartanus n. sp. is described based on male and female collected in Caicubi, state of Roraima, Brazil; and Ariston aglasices n. sp. is described based on a female collected in Bonampak, Chiapas, Mexico.

Conclusions

An emended diagnosis for Ariston and Siratoba and for each previously known species is provided. In total, five species are recognized in Ariston, including two new species, and two species are recognized in Siratoba.

Keywords

New World Mexico Brazil Taxonomy New species Deinopoidea

Background

Ariston O. P.-Cambridge, 1896 and Siratoba Opell, 1979 are two poorly known genera of spiders of Uloboridae. Species from both genera can be diagnosed based on their small size, with females' length being less than 2.5 mm, and a posterior epigynal hood (Opell [1979]), which lead to the hypothesis they are closely related. This hypothesis was supported by Coddington ([1990]) as both genera share the radix as an embolic guide, a flat embolus, and the absence of a stridulatory apparatus.

The genus Ariston was described by O. P.-Cambridge (1896) based on an adult female type species A. albicans O. P.-Cambridge, 1896, from Tabasco, Mexico. Kraus ([1955]) extended the distribution of this species for Honduras (Islas de la Bahía). In [1942], Gertsch and Davis described one more species, Ariston reticens, based on an adult male from San Luis Potosi, Mexico. The later species was placed in Ariston with some doubt, supported only by the difference on the interdistance of the eyes between this species and A. albicans. Opell ([1979]) revised A. albicans and described two new species, A. mazolus based on adult male from Colima, Mexico, and A. aristus, based on adult females from Barro Colorado Island, Panama. In this same paper, he erected the genus Siratoba to include the type species Ariston referens Muma and Gertsch, [1964] from Cochise, Arizona and S. sira from San Luis Potosi in Mexico.

In his revision, Opell ([1979]) was not able to provide a diagnosis based on the male and female genitalia characters for the genera because when he studied the species samples of both sexes for all species were not available. He provided then a diagnosis for Ariston and Siratoba based on the presence of a prominent epigynal hood, interdistance of the eyes, presence of an abdominal middle peak, and the small body size of the species characteristic for both genera compared to other uloborids.

In this paper, we provide an emended diagnosis for each genus, and for all species included. For both, genera and species diagnosis, characters of the male palpus and epigynum as described by Opell ([1979]), and newly examined characters were used. We also described the male of A. albicans for the first time based on material from the type locality; two new species of Ariston are described, one based on male and female collected in the state of Roraima, Amazon basin, Brazil, and the other based on a female from Bonampak, Chiapas, Mexico; and finally, A. reticens Gertsch and Davis, 1942 is transferred to Siratoba based on the new diagnosis herein proposed for the genus.

Methods

The terminology for anatomical structures follows Opell ([1979]). Epigynes were cleared with clove oil. Palpi were cleared with methyl salicylate. The genital structures were examined, and pencil sketches were made under Leica MZ AP0 stereoscope (Milton Keynes, UK). The specimens were photographed using a Leica M205A stereoscopic microscope equipped with a Leica DFC425 camera and LAS software, and also some images were refined using Helicon Focus (version 5.3) software from Helicon Soft Ltd. (Kharkov, Ukraine; www.heliconsoft.com). The images were edited in Adobe Photoshop CS4 Extended (version 11.0.2). Both images and sketches were used as templates to trace vector graphics in an Adobe Illustrator CS4 (version 14.0.0). Measurements are in millimeters. The distribution maps were created using ArcView version 9.

The specimens examined for this study are deposited in the following institutions (abbreviations and curators are given in parentheses): American Museum of Natural History (AMNH, N.I. Platnick), California Academy of Science (CAS, C. Griswold), Colección Nacional de Arácnidos/Instituto de Biología - Universidad Nacional Autónoma de México (CNAN/UNAM, O.F. Francke), Instituto Nacional de Pesquisas da Amazônia (INPA, A. Henriques), and Museum of Comparative Zoology (MCZ, G. Giribet).

Systematics

Family Uloboridae Thorell, 1869

Genus Ariston O. Pickard-Cambridge, 1896

Ariston O. P.-Cambridge, 1896: 216. Type species by monotypy: A. albicans O. P.-Cambridge, 1896.

Diagnosis. Males differ from those of Siratoba by having a flat and hook-like radix (Figure 1d); heavily sclerotized, flat, and curved embolus arising anteriorly to the radix; heavily sclerotized and elongated median apophysis with a curved apex (Figures 2c,d and 1c); long and swan-neck shape conductor arising between the basis of median apophysis and radix and extends between distal portions of these sclerites; presence of a conductor spike (Figures 3a,b,c,d,e,f,g,h, 2a,b, and 1a,b; Opell ([1979]): pl. 3a,b; 1981: Figure one). Females possess a notch instead of a posterior hood as present in Siratoba species (Figures 4 c,e,g, 5d, and 6e) and spermathecae occupying the lateral and middle area of vulva (Figures 4d,f,h, 7e, 5b,d, and 6f).
Figure 1

Ariston spartanus n. sp. (a) Male, palpus, retrolateral view; (b) prolateral view; (c) median aphophysis, ventrolateral view; (d) radix and embolus, anterior view. (e) Female, epigynum, ventral view; (f) cleared, dorsal view. Scale bars: (a,b,c,d) 0.1 mm, (e,f) 0.5 mm. co, conductor; cs, conductor spike; cy, cymbium; e, embolus; f, fundus; ma, median apophysis; p, epigynal pit; r, radix; s, spermathecae; st, subtegulum; te, tegulum.

Figure 2

Ariston albicans O. P. Cambrigde, 1896, male, palpus. (a) Retrolateral view, (b) prolateral view, (c) median aphophysis, dorsolateral view, (d) same, prolateral view. Scale bars: (a,b,c,d) 0.5 mm. co, conductor; cs, conductor spike; cy, cymbium; e, embolus; f, fundus; ma, median apophysis; r, radix; st, subtegulum; te, tegulum.

Figure 3

Palp of Ariston species, cleared. (a) Ariston albicans O. P. Cambridge, 1896, prolateral view, (b) retrolateral view; (c) Ariston aristus Opell, 1979, prolateral view, (d) retrolateral view; (e) Ariston mazolus Opell, 1979, prolateral view, (f) retrolateral view; (g) Ariston spartanus n. sp., prolateral view, (h) retrolateral view. Scale bars: (a,b,c,d,e,f,g,h) 0.1 mm. co, conductor; cs, conductor spike; cy, cymbium; e, embolus; f, fundus; ma, median apophysis; r, radix; st, subtegulum; te, tegulum.

Figure 4

Ariston albicans O. P. Cambrigde, 1896, male. (a) Habitus, (b) dorsal view, (c) carapace, anterior view, (d) abdomen, ventral view, (e) carapace, ventral view. Scale bars: (a,b,c,d,e) 0.5 mm.

Figure 5

Epigyne of Siratoba and Ariston species. (a) Siratoba reticens (Gertsch and Davis 1942) n. comb., ventral view, (b) posterior view; (c) Ariston aristus Opell, 1979, ventral view, (d) posterior view; (e) Ariston mazolus Opell, 1979, ventral view, (f) posterior view; (g) Ariston albicans O. P. Cambrigde, 1896, ventral view, (h) posterior view. Scale bars: (a,b,c,d,e,f) 0.1 mm. ag, accessory gland; h, epigynal hood; n, epigynal notch; pp, posterior plate; s, spermathecae.

Figure 6

Ariston aglasices n. sp., female. (a) lateral view, (b) dorsal view, (c) carapace, anterior view, (d) same, ventral view, (e) epigynum, ventral view, (f) same, dorsal view, not cleared. Scale bars: (a,b) 0.5 mm, (c,d) 0.25 mm, (e,f) 0.1 mm. n, epigynal notch; s, spermathecae.

Figure 7

Ariston aglasices n. sp. epigynum, and cymbium of Ariston species. (a) Ariston aglasices n. sp., epigynum, ventral view, (b) cleared, dorsal view; (c) Ariston albicans O. P. Cambridge, 1896, cymbium, dorsal view; (d) Ariston aristus Opell, 1979, cymbium, dorsal view; (e) Ariston mazolus Opell, 1979, cymbium, dorsal view; (f) Ariston spartanus n. sp., cymbium, dorsal view. Scale bars: (a,b,c,d,e,f) 0.1 mm. cy, cymbium; n, epigynal notch; s, spermathecae; ti, tibia.

Ariston aglasices new species (Figures 5a,b, 6a,b, and 8)
Figure 8

Ariston spartanus n. sp., male. (a) Lateral view, (b) dorsal view, (c) carapace, anterior view, (d) carapace, ventral view, (e) abdomen, ventral view. Scale bars: (a,b) 0.5 mm, (c,d,e) 0.25 mm.

Type material. Female holotype from community of Bonampak (16°42′21.88″N, 91°3′50.98″W), Chiapas, Mexico, 28.x.2005, F. Álvarez-Padilha leg., deposited in MCZ.

Diagnosis. Females resemble those from A. spartanus n. sp. and A. albicans by the disposition and shape of the spermathecae, but it differs from all species of the genus by the much broader notch (Figures 5e,f and 6a,b), differs from A. aristus by not having distinct lobes on the posterior margin of epigynum (Figure 6b), from A. mazolus by the sinuous copulatory ducts (Figure 6b), and from A. spartanus n. sp. by the absence of a pit on the anterior margin of epigynum (Figure 6a).

Etymology. The epithet is masculine. Aglasices was Ariston's father and the King of Sparta between c. 575 and 550 BC.

Description

  • Female (MCZ). Total length: 2.19. Carapace: 0.63 in length, 0.56 in width. Eyes: AME-AME: 0.09/AME-ALE: 0.09/PME-PME: 0.15/PME-PLE: 0.04/ALE-ALE: 0.36/PLE-PLE: 0.31. Abdomen: 1.56 in length, 1.0 in width. Formula for the legs: I > IV > II > III. Measurements of the legs : I: femur 1.3/patella 0.3/tibia 1.3/metatarsus 1.2/tarsus 0.5/total 4.6. II: 0.9/0.3/0.6/0.6/0.3/2.7. III: 0.7/0.2/0.3/0.4/0.3/1.9. IV: 1.0/0.3/0.7/0.6/0.4/3.0. Carapace: round and longer than wide; shallow thoracic furrow; light bluish green with dark median bands (Figure 6b). Eye tubercles with black outline; AE and PE rows slightly recurved; AME slightly larger than the other eyes; PME's tubercles elongated; PLE's tubercles slightly elongated (Figure 6b,c). Chelicerae orange. Sternum and legs dark bluish green (Figure 6d). Abdomen: oval, pale bluish green with irregular white (guanine) spots dispersed throughout the length, and lateral sides and ventral abdomen light tan (Figure 6a,b). Calamistrum present. Epigynum: epigynal field sclerotized and wider than long, with a proeminent and broad notch (Figures 5a and 6e); four spermathecae with lateral spermathecae two times the diameter of the median spermathecae (Figures 5b and 6f); and copulatory ducts slightly sinuous (Figure 5b).

  • Male. Unknown.

Distribution. Known only from the type locality, Bonampak, Chiapas, Mexico (Figure 8).

Ariston albicans O. Pickard-Cambridge, 1896 (Figures 3a,b, 4g,h, 9a,b,c,d,e, 2a,d, 6c, and 8)
Figure 9

Distribution map of Ariston species.

Ariston albicans O. Pickard-Cambridge, [1896]: 216, pl. 27, Figure nine (three female syntypes from Teapa, 17°34′1.58″N 92°57′0.23″W, Tabasco, Mexico, H. H. Smith leg., deposited in BMNH, not examined); Simon ([1903]): 973; Kraus ([1955]): 79, Figures two hundred twenty-four to two hundred twenty-five; Lehtinen ([1967]): 463, Figures four hundred eighty-nine and four hundred ninety-two; Opell ([1979]): 478, Figures thirty-two to thirty-five; Platnick ([2014]).

Material examined Mexico, Chiapas, Reserva de La Biosfera La Encrucijada (15°4′5.59″N, 92°45′20.02″W), 16.iv.2003, Y. Garcia leg, 38♀14♂102j (CNAN 2664; 2653; INPA 8801). Guatemala, El Petén Tikal, 7 to 11.x.1977, M. M. Bentzien leg, 1♂ (CAS).

Diagnosis. Males can be distinguished from other species of this genus by the presence of three spines on the posterolateral margin of the cymbium (Figures 3a, 2a, and 6c); they also differ from A. aristus and A. spartanus n. sp. by the embolus bended towards radix and median apophysis (Figures 3a,b and 2a,b); from A. spartanus n. sp. by the embolus free, not lied on radix (Figures 3a,b and 2a,b); and from A. mazolus by the embolus and radix not bended towards and covering the conductor (Figure 3d). Females resemble those from A. spartanus n. sp. and A. aglasices by the disposition and shape of the spermathecae, but differs from A. spartanus n. sp. by the presence of notch instead of a pit and differs from A. aglasices by the much narrower notch (Figure 4g,h). They differ from A. aristus by not having a posterior margin forming two distinct lobes (Figure 4d) and from A. mazolus by the copulatory ducts sinuous (Opell ([1979]): Figure thirty-four).

Description

  • Male (INPA 8801). Total length: 2.03. Carapace: 0.78 in length, 0.72 in width. Eyes: AME-AME: 0.07/AME-ALE: 0.04/PME-PME: 0.14/PME-PLE: 0.02/ALE-ALE: 0.35/PLE-PLE: 0.35. Abdomen: 1.25 in length, 0.65 in width. Formula for the legs: I > IV > II > III. Measurements of the legs: I: femur 0.9/patella 0.2/tibia 1.3/metatarsus 1.1/tarsus 0.4/total 3.9. II: 0.6/0.2/0.5/0.5/0.3/2.1. III: 0.5/0.1/0.3/0.3/0.2/1.4. IV: 0.8/0.2/0.6/0.4/0.3/2.3. Carapace: round and slightly longer than wide; shallow thoracic furrow; light yellow with green dark median bands (Figure 9a). Tubercles of eyes have black outline; AE and PE rows slightly recurved; AME larger than the other eyes (Figure 9b,c). Chelicerae pale yellow. Sternum, ventral abdomen, and legs pale yellow to light tan (Figure 9e,d). Abdomen: oval, tan yellow to dark green with irregular white spots dispersed throughout the length; lateral sides of the abdomen darkish. Calamistrum absent. Palpus: tibia palpal with two apical short ridges; long and curved tip radix (Figure 2a,b); conductor's tip strongly sclerotized (fig.a − b); median apophysis divided; ma1 smaller than ma2, both with curved tip, median apophysis shape as in Figure 2c,d; cymbium shape as in Figure 6c.

  • Female. Described in Opell ([1979]): 480 to 481, Figures thirty-two to thirty-five.

Remarks. Although not examined, the illustration of the material collected in Islas de la Bahia, Honduras (one female SMF 8698, Peters Leg. 9. 1951) published by Kraus ([1955]) allowed the identification of this material as A. albicans, and it was included here in the species distribution.

Distribution. Tabasco and Chiapas (Mexico), El Petén Tikal (Guatemala), and Islas de la Bahia (Honduras) (Figure 9).

Ariston aristus Opell, 1979 (Figures 3c,d, 4c,d, 6b, 10d,e,f,g, and 9)
Figure 10

Palp of Ariston mazolus Opell, 1979 and Ariston aristus Opell, 1979. Ariston mazolus Opell, 1979 (a) retrolateral, (b) conductor and conductor spike, retrolateral view, (c) median aphophysis, prolateral view. Ariston aristus Opell, 1979 (d) retrolateral view, (e) conductor and conductor spike, retrolateral view, (f) median aphophysis, retrolateral view, (g) same, apical view. Scale bars: (a,b,d,e) 0.1 mm, (c,f,g) 0.05 mm. co, conductor; cs, conductor spike; cy, cymbium; e, embolus; f, fundus; ma, median apophysis; r, radix; st, subtegulum; te, tegulum.

Ariston aristus Opell, 1979: 482, Figures forty to forty-five (female holotype, VIII.1939, A.M. Chickering leg., 20 to 24.VI., N. Banks leg, both collected from Barro Colorado Island, 9°9′7.57″N 79°50′47.33″W, Canal Zone, Panama; and male paratype described in Opell, 1981 from the same locality as holotype; both deposited in MCZ, examined); Opell, 1981; Platnick [2014].

Diagnosis. Males can be distinguished from A. albicans by the lack of spines on cymbium (Figures 3c and 2a), from A. mazolus and A. spartanus n. sp. by the embolus bended towards radix and median apophysis (Figure 3d), and from A. spartanus n. sp. by the embolus free, not lied on radix (Figures 3d and 10d). Females differ from all other species of Ariston by the posterior margin of the epigynum forming two lobes with a median notch, accessory glands twice the size of the spermathecae diameter, and copulatory ducts situated transversely in relation to the posterior margin of the epigynum (Figure 4d).

Description. Female described by Opell [1979]: 482, Figures forty to forty-five, and male by Opell, 1981: 219, Figures one and six.

Distribution. Canal Zone, Panama (Figure 9).

Ariston mazolus Opell, 1979 (Figures 3e,f, 4c,d, 6c, 10a,b,c, and 9)

Ariston mazolus Opell, [1979]: 481, Figures thirty-six to thirty-nine, pl. 3A-B (female holotype and three male paratypes from Miramar, 19°7′16.76″N 104°22′18.90″W, Manzanillo, Colima, Mexico, F. Bonet leg, deposited in AMNH, examined); Platnick ([2014]).

Diagnosis. Males resemble those from A. spartanus n. sp. by the embolus bended towards radix and median apophysis, but differ by the embolus not lied on the inner surface of radix (Figures 3f and 10a); they also differ from A. albicans by lack of spines on cymbium (Figures 3e and 6c). Females are distinguished from all other species, externally by having the narrower notch on the anterior margin of epigynum (Figure 4e,f); they also differ from A. aristus by the disposition of spermathecae, the absence of lobes on posterior margin of epigynum, and by the copulatory ducts situated diagonally in relation to the posterior margin of the epigynum (Figure 4e,f); from A. albicans by the copulatory ducts not sinuous; and from A. spartanus n. sp. by not present a pit on the anterior margin of epigynum (Figure 4e,f).

Description. Male and female described in Opell ([1979]):481, Figures thirty-six to thirty-nine, pl. 3A-B.

Distribution. Colima (Mexico) (Figure 9).

Ariston spartanus new species (Figures 3g,h, 7a,b,c,d,e, 11a,b,c,d,e,f,g, 1a,b,c,d,e,f, 6f, and 9)
Figure 11

Ariston spartanus n. sp., female. (a) Lateral view, (b) dorsal view, (c) abdomen, ventral view, (d) carapace, anterior view, (e) epigynum, ventral view, (f) carapace, ventral view, (g) epigynum, caudal view. Scale bars: (a,b,c) 0.5 mm, (d,f) 0.25 mm, (e,g) 0.1 mm. p, epigynal pit; s, spermathecae.

Type material. Male holoype from community of Caicubi (1°0′32.04″S, 62° 7′10.56″W), Caracaraí, Roraima, Brazil, visual nocturnal search, 25.x.2008, A.L. Tourinho leg., deposited in INPA 8800.

Diagnosis. Males resemble those from A. mazolus by the embolus bended towards radix and median apophysis, but differ from this and all other species by the embolus lied on the inner surface of radix (Figure 1d); they also differ from A. albicans by lacking spines on the posterolateral margin of the cymbium (Figures 3c and 10d). Females can be readily recognized by the presence of a furrow; all other Ariston species present a notch (Figures 11e and 1e).

Etymology. The epithet is masculine, and Latin for Sparta was chosen here in reference to the historical name of the genus who was the Greek king 'Aρίστων (Ariston), the King of Sparta during the Battle of the Fetters, between c. 550 and 515 BC.

Description

  • Male (INPA 8800). Total length: 1.55. Carapace: 0.60 in length, 0.61 in width. Eyes: AME-AME: 0.09/AME-ALE: 0.04/PME-PME: 0.14/PME-PLE: 0.06/ALE-ALE: 0.32/PLE-PLE: 0.32. Abdomen: 0.95 in length, 0.62 in width. Formula for the legs: I > II > IV > III. Measurements for the legs: I: femur 0.9/patella 0.2/tibia 1.0/metatarsus 0.9/tarsus 0.4/total 3.4. II: 0.7/0.2/0.6/0.6/0.3/2.4. III: 0.6/0.1/0.3/0.4/0.2/ 1.6. IV: 0.7/0.2/0.5/0.5/0.3/2.2. Carapace: round and slightly wider than long; shallow thoracic furrow; light green from clypeus to median area and dark green median bands (Figure 7b,c). Eyes tubercles outline black; PE's tubercles slightly elongated; AE rows slightly procurved; PE rows recurved; AME twice the size of the other eyes (Figure 7b,c). Eye area with several black thick setae. Chelicerae light green. Sternum and ventral abdomen green (Figure 7d,e). Legs green with orange shades (Figure 7a). Abdomen oval, pale white with lateral sides of the abdomen dark to light green (Figure 7a,b). Calamistrum absent. Prolateral row of trichobothria on femur II to V. Palpus: tibia palpal without apical ridges, long and curved tip radix (Figure 1b,d); conductor's tip strongly sclerotized (Figure 1a,b); median apophysis divided; ma1 smaller than ma2, both with curved tip, median apophysis shape as in Figure 1c; cymbium shape as in Figure 6f.

  • Female (INPA 8880). Total length: 1.89. Carapace: 0.64 in length, 0.61 in width. Eyes: AME-AME: 0.08/AME-ALE: 0.03/PME-PME: 0.12/PME-PLE: 0.06/ALE-ALE: 0.30/PLE-PLE: 0.29. Abdomen: 1.25 in length, 1.10 in width. Formula for the legs: I > II > IV > III. Measurements for the legs: I: femur 1.3/patella 0.3/tibia 1.1/metatarsus 1.0/tarsus 0.4/total 4.1. II: 0.8/0.2/0.5/0.5/0.3/2.3. III: 0.5/0.2/0.3/0.4/0.3/1.7. IV: 0.6/0.2/0.6/0.5/0.3/2.2. Carapace: round and slightly longer than wide; shallow thoracic furrow; light green from clypeus to median area, and dark green median bands (Figure 11a,b). Eye tubercles have black outline; PE's tubercles slightly elongated; AE and PE rows recurved; AME larger than the other eyes (Figure 11b,d). Chelicerae light green. Sternum, ventral abdomen, and legs green (Figure 11c,f). Abdomen: oval, light white to light brown with irregular white (guanine) spots dispersed throughout the length; lateral sides of the abdomen dark to light green (Figure 11a,b). Calamistrum present. Prolateral row of trichobothria on femur II to V. Epigynum: epigynal field sclerotized and wider than long, has four spermathecae with equal sizes, and copulatory ducts not sinuous (Figures 11e,g and 1e,f).

Distribution. Known only from the type locality, Caicubi, Roraima, Brazil (Figure 9).

Genus Siratoba Opell, 1979

Siratoba Opell, [1979]: 486. Type species by original designation: A. referens Muma & Gertsch, 1964.

Diagnosis. Males differ from Ariston by the coiled radix with a central groove in which the thin and curved embolus lies, u-shaped conductor, and small and not projected median apophysis (Figures 12a,b,c,d,e,f; Gertsch and Davis ([1942]), Figure forty-three; Opell ([1979]): pl. 3c-d, Figure sixty-eight to sixty-nine; Coddington ([1990]): Figure forty-two; Roth ([1982]): Figure three; Roth ([1985]): Figure three; Roth ([1994]), Figure three). Females differ from those of Ariston by the presence of a heavily sclerotized posterior plate and the presence of a prominent ventral hood instead of a notch as present on Ariston species; spermathecae occupying only the lateral area of vulva (Figure 4a,b; Muma and Gertsch ([1964]): Figure thirty-seven; Opell ([1979]): Figures sixty-five to sixty-seven and seventy-five to seventy-seven; Roth ([1982]): Figure two; Roth ([1985]): Figure two; Roth ([1994]), Figure two).
Figure 12

Palp of Siratoba species. (a) Siratoba referens (Muma and Gertsch [1964]), retrolateral view, (b) prolateral view; (c) Siratoba reticens (Gertsch and Davis [1942]) n. comb., retrolateral view, (d) prolateral view; (e) Siratoba referens (Muma and Gertsch [1964]), posterior view; (f) Siratoba reticens (Gertsch and Davis [1942]) n. comb., posterior view. Scale bars: (a,b,c,d,e) 0.2 mm. co, conductor; e, embolus; f, fundus; ma, median apophysis; r, radix; te, tegulum; ts, tegular spur.

Siratoba referens (Muma and Gertsch [1964]; Figures 12a,b,e, 13a,f,g,h, and 14)
Figure 13

Cymbium and palp sclerites of Siratoba species. (a) Siratoba referens (Muma and Gertsch [1964]), cymbium, dorsal view; (b) Siratoba reticens (Gertsch and Davis [1942]) n. comb., cymbium, dorsal view; (c) Siratoba reticens (Gertsch and Davis [1942]) n. comb., palpus, anterior view, (d) details of the tegular spur and median apophysis, prolateral view, (e) same, retrolateral view; (f) Siratoba referens (Muma and Gertsch [1964]), palpus, anterior view, (g) details of the tegular spur and median apophysis, prolateral view, (h) same, retrolateral view. Scale bars: (a,b) 0.3 mm, (c,f) 0.2 mm, (d,e) 0.5 mm, (g) 0.1 mm, (h) 0.2 mm. cy, cymbium; e, embolus; ma, median apophysis; r, radix; te, tegulum; ts, tegular spur.

Figure 14

Distribution map of Siratoba species.

Ariston referens Muma and Gertsch, [1964]: 17, Figures thirty-six to thirty-nine (male holotype and female paratype from Cochise Stronghold, 31°56′22.30″N 109°58′55.25″W, Dragoon Mountains, Arizona, W. J. Gertsch leg., deposited in the AMNH, male examined, female not examined).

Siratoba referens: Opell ([1979]): 488, Figures sixty-five to seventy-four, pl. 3C-D (n. comb.); Roth ([1982]): 50 to 1, Figures two to three; Roth ([1985]), B46-3, Figures two to three; Roth ([1994]): 192, Figures two to three; Coddington ([1990]), Figure forty-two; Platnick ([2014]).

Diagnosis. Males differ from those of S. reticens by the radix forming a short curl, embolus, and radix of same size, and the dorsal margin of radix not indented (Figure 12a,b,e; Muma and Davis ([1964]), Figure thirty-seven). Females differ from those of S. reticens by the broad hood and the lack of a pit on its tip on the anterior margin of epigynum (Opell ([1979]): Figure sixty-five), posterior plate's margin concave (Opell ([1979]): Figures sixty-five to sixty-seven), and coiled copulatory duct in a parallel position in relation to the posterior margin of epigynum (Opell ([1979]): Figure sixty-seven).

Description. Male and female described by Muma and Gertsch ([1964]): 17, Figures thirty-six to thirty-nine and redescribed in Opell ([1979]): 488, Figures seventy-five to seventy-seven.

Distribution. Dragoon Mountains, AZ, USA (Figure 14).

Siratoba reticens (Gertsch and Davis [1942]) new combination (Figures 4a,b, 12c,d,f, 13b,c,d,e, and 14)

Ariston reticens Gertsch and Davis, [1942]: 17, Figure forty-three (male holotype and two immature paratypes from 23 miles east of Ciudad del Maiz, 22°23′59.46″N 99°36′10.59″W, San Luis Potosi, Mexico, A.M. Davis leg., deposited in AMNH, examined). Roewer ([1955]): 1335; Platnick ([2014]).

Siratoba sira Opell, 1979; Platnick, 2014 (female holotype from entrance of cave Taninuí, 21°57′24.58″N 98°53′19.23″W, San Luis Potosi, Mexico, 29.III. 1940, W. Bridge leg., deposited in AMNH, examined); Platnick ([2014]). New synonym

Diagnosis. Males differ from S. referens by the radix forming a long curl, the embolus shorter than the radix, and the dorsal margin of radix indented (Figure 12c,d,f; Gertsch and Davis ([1942]): Figure forty-three). Females differ from those of S. referens (Opell ([1979]): Figures sixty-five to sixty-seven) by the narrower hood and presence of a pit on its tip (Figure 4a), posterior plate's margin convex (Opell ([1979]): Figures seventy-five to seventy-six), and coiled copulatory duct in a transverse position in relation to the posterior margin of epigynum (Opell ([1979]): Figure seventy-seven).

Remarks. Both Ariston reticens and Siratoba sira were described based on one sex. Having examined the holotypes of both nominal species and being the proximity of the locality types, we were unable to find differences justifying their separation, which has led us to consider the examined specimens to be conspecific. Therefore, we synonymized Siratoba sira under Ariston reticens.

Description. Male described by Gertsch and Davis ([1942]): 17, f. 43, and female described by Opell ([1979]): 490, f. 75 to 77.

Distribution. San Luis Potosi (Mexico) (Figure 14).

Results and discussion

The diagnosis presented here is a combination of the characters of palpus and epigynum described by Opell ([1979]) and new diagnostic characters found in the course of this study. The diagnostic characters recovered from Opell's revision ([1979]) were as follows: (1) the shape of radix, (2) the shape and orientation of embolus, (3) the shape of median apophysis, and (4) presence of the posterior hood. The new diagnostic characters added were the following: (1) the shape and orientation of conductor, (2) presence and shape of the conductor spike, (3) disposition of the spermathecae, (4) shape of cymbium, (5) presence of spines on cymbium, (6) orientation of the embolus, (7) shape of the copulatory ducts, and (8) presence of notch or pit on epigynum.

The total body length, ratios between carapace width and length and between first femur length and carapace length, the distances between the eyes and height of the clypeus, and distribution ranges were removed in this revised diagnosis because they are not sufficiently clear to distinguish neither genera nor species. For most species, the only material available to study were the type material, so the SEM photos could not be provided, and since the material is already too fragile, the genitalia were cleared only with clove oil.

The accessory glands described by Opell ([1979]) for almost all species of Ariston and Siratoba and the exact localization of the fertilization ducts could not be clearly visualized in most species; thus, those two characters were not described and used here. However, for A. aristus, the accessory glands could be easily seen, and it was used as diagnostic character for this species.

On the epigynum external morphology, a clear differentiation of epigynal notch, present in Ariston species, and epigynal hood, present in Siratoba species, is provided here: the first is a notch (that could be presented as a pit as in A. spartanus n. sp.) on the anterior portion of the epigynal area that is not prominent enough to overlay the epigynal area in ventral view and is not associated with a posterior plate, and a epigynal hood is in the same portion of the epigynal areas as in the notch but is prominent enough to overlay the epigynal area and the posterior plate is present.

On males, the conductor spike was identified in Ariston species, and tegular spur in Siratoba species. The conductor spike, also present in Philoponella species (Opell, [1979]), is described here as a weakly (as in A. aristus and A. mazolus) to heavily sclerotized spike (as in A. albicans and A. spartanus n. sp.) arising above the conductor with variable shapes among the species. And the tegular spur is present in Zosis, Octonoba, and Purumitra (Opell [1979]) arising from the lateral tegular surface; in Siratoba, it arises from the apical portion of the tegulum.

The distal portion of the palpus to the median apophysis is less pleated and is slightly sclerotized, so we considered subtegulum the more distal and less sclerotized portion that bears the fundus, and tegulum the more apical and sclerotized portion. In Opell's revision ([1979]), he identified tegulum as the distal surface which arises from the median apophysis, and the remaining area of the distal portion were left unnamed. Here, no visible differentiation that would let the area of hematodocha be identified more clearly was found. In Ariston species, the median apophysis is present and can be an elongated projection without prongs (A. mazolus), with one prong (A. albicans and A. aristus), or three prongs (A. spartanus n. sp.).

Conclusions

In total, five species are recognized in Ariston, including two new species, and two species are recognized in Siratoba. New diagnostic characters are suggested for defining the genera and their species. Unfortunately, data about natural history of those species remains unknown.

Abbreviations

AE:

anterior eyes

AME:

anterior median eyes

PE:

posterior eyes

PME:

posterior median eyes

ag:

accessory gland

co:

conductor

cs:

conductor spike

cy:

cymbium

e:

embolus

f:

fundus

h:

epigynal hood

l:

epigynal lobe

ma:

median apophysis

n:

epigynal notch

p:

epigynal pit

pp:

posterior plate

r:

radix

s:

spermathecae

st:

subtegulum

te:

tegulum

ti:

tibia

ts:

tegular spur

Declarations

Acknowledgements

We thank the curators for the loan of the material. To the Jufari Expedition team Cristina Rheims, Gonzalo Giribet, Gustavo Hormiga, Jesus Ballesteros, Ligia Benavides, Osmaildo F. da Silva, Thiago da S. Moreira, Rafael Indicatti and Willians Porto and the crew of Vitória Amazônica Foundation. The first author thanks Charles Griswold for providing an internal grant to visit the California Academy of Science (CAS). The Coordination of Improvement of Higher Education Personnel-CAPES (grant PNPD#03017/09-5 to ALT) and the Brazilian National Council for Scientific and Technological Development-CNPq through the Brazilian Research Program for Biodiversity-PPBio for Ph.D. fellowship to LSPT (CSF# 200494/2013-9) and by a CNPq (Proc. 301776/2004-0) to A.D. Brescovit.

Authors’ Affiliations

(1)
Coordenação de Biodiversidade, Instituto Nacional de Pesquisas da Amazônia (INPA)
(2)
Department of Biological Sciences, The George Washington University
(3)
Museum of Comparative Zoology, Department of Organismic and Evolutionary Biology, Harvard University
(4)
Laboratório Especial de Coleções Zoológicas, Instituto Butantan

References

  1. Coddington JA: Ontogeny and homology in the male palpus of orb-weaving spiders and their relatives, with comments on phylogeny (Araneoclada: Araneoidea, Deinopoidea). Smithson Contrib Zool 1990, 496: 1–52. [http://dx.doi.org/10.5479/si.00810282.496] http://dx.doi.org/10.5479/si.00810282.496 10.5479/si.00810282.496View ArticleGoogle Scholar
  2. Gertsch WJ, Davis LI: Report on a collection of spiders from Mexico. IV. Am Mus Novit 1942, 1158: 1–19.Google Scholar
  3. Kraus O: Spinnen aus El Salvador (Arachnoidea, Araneae). Abh Senckenb Naturforsch Ges 1955, 493: 1–112.Google Scholar
  4. Lehtinen PT: Classification of the cribellate spiders and some allied families, with notes on the evolution of the suborder Araneomorpha. Ann Zool Fenn 1967, 4: 199–468.Google Scholar
  5. Muma MH, Gertsch WJ: The spider family Uloboridae in North America north of Mexico. Am Mus Novit 1964, 2196: 1–43.Google Scholar
  6. Opell BD: Revision of the genera and tropical American species of the spider family Uloboridae. Bull Mus Comp Zool Harvard Univ 1979, 148: 443–549.Google Scholar
  7. Pickard-Cambridge O (1896) Arachnida. Araneida. In: Biologia Centrali-Americana, Zoology, vol 1. London, pp 161–224
  8. Platnick NI: The world spider catalog, version 12.5. American Museum of Natural History, New York; 2014.Google Scholar
  9. Roewer CF: Katalog der Araneae von 1758 bis 1940, bzw. 1954. Kommissions-Verlag von "Natura", Bruxelles; 1955.Google Scholar
  10. Roth VD: Handbook for Spider Identification. Roth, Portal; 1982.Google Scholar
  11. Roth VD: Spider genera of North America. American Arachnological Society, Gainesville; 1985.Google Scholar
  12. Roth VD: Spider genera of North America, with keys to families and genera, and a guide to literature. American Arachnological Society, Gainesville; 1994.Google Scholar
  13. Simon E: Histoire Naturelle des Araignées. Roret, Paris; 1903.Google Scholar
